Outer Diameter:48mm--60mm; 48mm--56mm; 40mm--48mm;
Pope Thickness:1.5mm--3mm
Length:600mm--5000mm
Standard:GB, ANSI, ASME, ASTM, JIS, DIN, BS, EN
Material:Q195,Q235, Q345
Package:in pallets or in bundle or in bulk
Surface Treatment:painted, pre-galvanized, powder painted, hot dipped galvanized
Type:heavy duty or light duty
Application:slab or formwork supporting
Weight:4.74kg--30kg
Component:bottom plate, outer tube, inner tube, swivel nut,cotter pin, upper plate
| Italian Prop | |||
| Adjustable Length | Outer Tube | Inner Tube | Wall Thickness |
| 1600-2900mm | 56mm | 48mm | 1.5-2.75mm |
| 1800-3100mm | |||
| 2000-3600mm | |||
| 2200-4000mm | |||
| Surface Treatment | Painted,powder coated,electro galvanized or hot dip galvanized | ||
| Middle East or German Prop | |||
| Adjustable Length | Outer Tube | Inner Tube | Wall Thickness |
| 1400-2700mm | 60.3mm | 48.3mm | 1.6-4.0mm |
| 1600-2700mm | |||
| 1620-2640mm | |||
| 2000-3500mm | |||
| 2200-4000mm | |||
| 3000-5500mm | |||
| Surface Treatment | Painted,powder coated,electro galvanized or hot dip galvanized | ||
| Spain Prop | |||
| Adjustable Length | Outer Tube | Inner Tube | Wall Thickness |
| 800-1400mm | 48mm | 40mm | 1.5-2.5mm |
| 1600-3000mm | |||
| 2000-3500mm | |||
| 2200-4000mm | |||
| Surface Treatment | Painted,powder coated,electro galvanized or hot dip galvanized | ||
| Push Pull Prop | |||
| Adjustable Length | Outer Tube | Inner Tube | Wall Thickness |
| 1400-2700mm | 60.3mm | 48.3mm | 1.6-4.0mm |
| 1600-2700mm | |||
| 1620-2640mm | |||
| 2000-3500mm | |||
| 2200-4000mm | |||
| 3000-5500mm | |||
| Surface Treatment | Painted,powder coated,electro galvanized or hot dip galvanized | ||
